PIX Double Sided Hexagonal Wrap Belt CC Section 22 x 17 mm
PIX Double Sided Hexagonal Wrap Belt CC Section 22 x 17 mm 4786292752473
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
- Specification
- Description
|
Brand |
PIX |
|
Product Type |
Double Sided Hexagonal Wrap Belt |
|
Size |
CC 73, CC 108, CC 136, CC 160, CC 166, CC 180, CC 210, CC 254, CC 300, CC 900 |
|
Section |
CC Section |
|
Angle Degree |
40 |
|
Top Width |
22 mm |
|
Thickness |
17 mm |
|
Min Pulley Dia. (mm) |
224 dp |
|
Mfg. Range |
73 Inch to 900 Inch |
-
Enhanced Life
-
Transmits Power From Both The Sides
-
Center Cord Provides Excellent Power Transmission And Low-Stretch
-
Special Design Provides An Excellent Flexibility For Serpentine Drives
-
Temperature Range: -18°C to +80°C
-
Hexagonal Or Double V-Belts Are Recommended For Serpentine Drives, Where Power Is To Be Transmitted From Both The Sides Of The Belt
-
Double V-Belts Are Extremely Flexible, They Are Widely Used In Agricultural Machinery
-
They Are Meant For The Application Where Sudden Directional Changes In The Belt Travel Occur, These Changes Exerts A Unique Stress On The Structure Of The Belt
-
Pix-Double V-Belts Are Perfectly Designed And Remain Aligned Both Laterally And Longitudinally, In The Pulley Groove, While Operating
-
PIX Hexagonal Or Double V-Belts Are Antistatic And Oil Resistant
-
Application
-
Rice Mills, Husker Machines, Serpentine Drives, Poultry Feather-Pickers, Dyeing Units, Etc
Product Description
-
Enhanced Product Life
-
Transmits Power From Both The Sides
-
Center Cord Provides Excellent Power Transmission And Low-Stretch
-
Special Design Provides An Excellent Flexibility For Serpentine Drives
-
Temperature Range: -18°C to +80°C
-
Hexagonal Or Double V-Belts Are Recommended For Serpentine Drives, Where Power Is To Be Transmitted From Both The Sides Of The Belt
-
Double V-Belts Are Extremely Flexible, They Are Widely Used In Agricultural Machinery
-
They Are Meant For The Application Where Sudden Directional Changes In The Belt Travel Occur, These Changes Exerts A Unique Stress On The Structure Of The Belt
-
Pix-Double V-Belts Are Perfectly Designed And Remain Aligned Both Laterally And Longitudinally, In The Pulley Groove, While Operating
-
PIX Hexagonal Or Double V-Belts Are Antistatic And Oil Resistant
-
Application
-
Rice Mills, Husker Machines, Serpentine Drives, Poultry Feather-Pickers, Dyeing Units, Etc
Product Specification
|
Brand |
PIX |
|
Product Type |
Double Sided Hexagonal Wrap Belt |
|
Size |
CC 73, CC 108, CC 136, CC 160, CC 166, CC 180, CC 210, CC 254, CC 300, CC 900 |
|
Section |
CC Section |
|
Angle Degree |
40 |
|
Top Width |
22 mm |
|
Thickness |
17 mm |
|
Min Pulley Dia. (mm) |
224 dp |
|
Mfg. Range |
73 Inch to 900 Inch |
